Abracon符合AEC-Q200標準的汽車石英晶體現已上市,ABS07AIG-32.768kHz-9-D-1-T
來源：http://www.py519.com 作者：億金電子 2023年06月17
Abracon符合AEC-Q200標準的汽車石英晶體現已上市,ABS07AIG-32.768kHz-9-D-1-T，Abracon符合AEC-Q200標準的汽車石英晶體現已上市,ABS07AIG-32.768kHz-9-D-1-T，美國Abracon晶振符合AEC-Q200標準的汽車石英晶體現已上市
Abracon符合AEC-Q200標準的汽車石英晶體現已上市,ABS07AIG-32.768kHz-9-D-1-T，Abracon的ABS07AIG是一種高溫石英晶體諧振器，符合AEC-Q200標準，并通過TSI6949生產線認證。該器件具有-40℃至+125℃的寬工作溫度范圍，是極端環境中商業或工業應用的完美解決方案。憑借超薄外形，ABS07AIG可以在空間受限的設計中實現，如可穿戴設備或車輛的信息娛樂系統。
ABS07AIG石英晶體采用密封陶瓷封裝，在導航、智能手機和無線通信等應用中提供長期可靠性。雖然ABS07AIG系列可以執行無關緊要的要求，但它針對低功耗進行了優化，以延長電池壽命，使其成為各種應用的理想選擇。
| ABRACON編號 | 制造商 | 型號 | 頻率 | 頻率容差 | 負載電容 |
| ABM3-8.000MHZ-B4Y-T | Abracon晶振 | ABM3 | 8 MHz | ±30ppm | 18pF |
| ABM3-29.4912MHZ-B2-T | Abracon晶振 | ABM3 | 29.4912 MHz | ±20ppm | 18pF |
| ABM3-27.000MHZ-B2-T | Abracon晶振 | ABM3 | 27 MHz | ±20ppm | 18pF |
| ABM3-28.6363MHZ-B2-T | Abracon晶振 | ABM3 | 28.6363 MHz | ±20ppm | 18pF |
| ABM3-16.000MHZ-B2-T | Abracon晶振 | ABM3 | 16 MHz | ±20ppm | 18pF |
| ABM3-12.288MHZ-D2Y-T | Abracon晶振 | ABM3 | 12.288 MHz | ±20ppm | 18pF |
| ABM3-27.000MHZ-D2Y-T | Abracon晶振 | ABM3 | 27 MHz | ±20ppm | 18pF |
| ABM3-30.000MHZ-D2Y-T | Abracon晶振 | ABM3 | 30 MHz | ±20ppm | 18pF |
| ABM3-32.000MHZ-D2Y-T | Abracon晶振 | ABM3 | 32 MHz | ±20ppm | 18pF |
| ABM3-9.8304MHZ-D2Y-T | Abracon晶振 | ABM3 | 9.8304 MHz | ±20ppm | 18pF |
| ABS09-32.768KHZ-T | Abracon LLC | ABS09 | 32.768 kHz | ±20ppm | 12.5pF |
| ABS09-32.768KHZ-9-T | Abracon LLC | ABS09 | 32.768 kHz | ±20ppm | 9pF |
| ABS07-32.768KHZ-T | Abracon LLC | ABS07 | 32.768 kHz | ±20ppm | 12.5pF |
| ABS07-32.768KHZ-7-T | Abracon LLC | ABS07 | 32.768 kHz | ±20ppm | 7pF |
| ABS07-166-32.768KHZ-T | Abracon LLC | ABS07 | 32.768 kHz | ±10ppm | 7pF |
| ABS07-32.768KHZ-9-T | Abracon LLC | ABS07 | 32.768 kHz | ±20ppm | 9pF |
| ABS07AIG-32.768KHZ-9-T | Abracon LLC | ABS07AIG | 32.768 kHz | ±20ppm | 9pF |
| ABS07AIG-32.768KHZ-9-D-T | Abracon LLC | ABS07AIG | 32.768 kHz | ±20ppm | 9pF |
| ABS07-32.768KHZ-9-4-T | Abracon LLC | ABS07 | 32.768 kHz | ±30ppm | 9pF |
| ABS07L-32.768KHZ-T | Abracon LLC | ABS07L | 32.768 kHz | ±20ppm | 12.5pF |
| ABS07-32.768KHZ-1-T | Abracon LLC | ABS07 | 32.768 kHz | ±10ppm | 12.5pF |
| ABS05-32.768KHZ-T | Abracon LLC | ABS05 | 32.768 kHz | ±20ppm | 12.5pF |
| ABS05-32.768KHZ-9-T | Abracon LLC | ABS05 | 32.768 kHz | ±20ppm | 9pF |
| ABS06-32.768KHZ-T | Abracon LLC | ABS06 | 32.768 kHz | ±20ppm | 12.5pF |
| ABS06-32.768KHZ-9-T | Abracon LLC | ABS06 | 32.768 kHz | ±20ppm | 9pF |
| ABS06-32.768KHZ-1-T | Abracon LLC | ABS06 | 32.768 kHz | ±10ppm | 12.5pF |
| ABS05-32.768KHZ-7-T | Abracon LLC | ABS05 | 32.768 kHz | ±20ppm | 7pF |
| ABS05-32.768KHZ-X-T5 | Abracon LLC | ABS05 | 32.768 kHz | ±20ppm | 4pF |
| ABM3-13.560MHZ-B2-T | Abracon晶振 | ABM3 | 13.56 MHz | ±20ppm | 18pF |
| ABS05-32.768KHZ-6-T | Abracon LLC | ABS05 | 32.768 kHz | ±20ppm | 6pF |
| ABS05-32.768KHZ-X-3-T3 | Abracon LLC | ABS05 | 32.768 kHz | ±25ppm | 4pF |
| ABM3-18.432MHZ-D2Y-T | Abracon晶振 | ABM3 | 18.432 MHz | ±20ppm | 18pF |
| ABS06-32.768KHZ-9-1-T | Abracon LLC | ABS06 | 32.768 kHz | ±10ppm | 9pF |
| ABS05W-32.768KHZ-K-2-T | Abracon LLC | ABS05W | 32.768 kHz | ±20ppm | 4pF |
| ABS07-32.768KHZ-4-T | Abracon LLC | ABS07 | 32.768 kHz | ±30ppm | 4pF |
| ABS07-32.768KHZ-9-H-T | Abracon LLC | ABS07 | 32.768 kHz | ±20ppm | 9pF |
| ABS07AIG-32.768KHZ-7-D-T | Abracon LLC | ABS07AIG | 32.768 kHz | ±20ppm | 7pF |
| ABS25-32.000KHZ-T | Abracon LLC | ABS25 | 32 kHz | ±30ppm | 12.5pF |
| ABS05W-32.768KHZ-J-2-T | Abracon LLC | ABS05W | 32.768 kHz | ±20ppm | 4pF |
| ABS06-32.768KHZ-7-T | Abracon LLC | ABS06 | 32.768 kHz | ±20ppm | 7pF |
| ABS25-60.000KHZ-T | Abracon LLC | ABS25 | 60 kHz | ±30ppm | 12.5pF |
| ABM3-36.000MHZ-B4Y-T | Abracon晶振 | ABM3 | 36 MHz | ±30ppm | 18pF |
| ABM3-29.4912MHZ-B4Y-T | Abracon晶振 | ABM3 | 29.4912 MHz | ±30ppm | 18pF |
| ABM3-40.000MHZ-B2-T | Abracon晶振 | ABM3 | 40 MHz | ±20ppm | 18pF |
| ABM3-24.576MHZ-B2-T | Abracon晶振 | ABM3 | 24.576 MHz | ±20ppm | 18pF |
| ABSM33A-3.6864MHZ-B4Y-T | Abracon LLC | ABSM3A | 3.6864 MHz | ±30ppm | 18pF |
| ABM3B-14.7456MHZ-E-4Z-T | Abracon晶振 | ABM3 | 14.7456 MHz | ±30ppm | 18pF |
| ABM3-50.000MHZ-D2Y-T | Abracon晶振 | ABM3 | 50 MHz | ±20ppm | 18pF |
| ABM3-9.8304MHZ-B4Y-T | Abracon晶振 | ABM3 | 9.8304 MHz | ±30ppm | 18pF |
| ABM3-12.288MHZ-B4Y-T | Abracon晶振 | ABM3 | 12.288 MHz | ±30ppm | 18pF |
| ABM3-15.000MHZ-B4Y-T | Abracon晶振 | ABM3 | 15 MHz | ±30ppm | 18pF |
| ABM3-16.384MHZ-B4Y-T | Abracon晶振 | ABM3 | 16.384 MHz | ±30ppm | 18pF |
| ABM3-24.000MHZ-B4Y-T | Abracon晶振 | ABM3 | 24 MHz | ±30ppm | 18pF |
| ABM3-27.000MHZ-B4Y-T | Abracon晶振 | ABM3 | 27 MHz | ±30ppm | 18pF |
| ABM3-48.000MHZ-B4Y-T | Abracon晶振 | ABM3 | 48 MHz | ±30ppm | 18pF |
| ABS13-32.768KHZ-T | Abracon LLC | ABS13 | 32.768 kHz | ±20ppm | 12.5pF |
| ABM3-18.432MHZ-B2-T | Abracon晶振 | ABM3 | 18.432 MHz | ±20ppm | 18pF |
| ABM3-12.000MHZ-B2-T | Abracon晶振 | ABM3 | 12 MHz | ±20ppm | 18pF |
| ABM3-14.31818MHZ-B2-T | Abracon晶振 | ABM3 | 14.31818 MHz | ±20ppm | 18pF |
| ABM3-20.000MHZ-B2-T | Abracon晶振 | ABM3 | 20 MHz | ±20ppm | 18pF |
| ABM3-24.000MHZ-B2-T | Abracon晶振 | ABM3 | 24 MHz | ±20ppm | 18pF |
| ABM3-25.000MHZ-B2-T | Abracon晶振 | ABM3 | 25 MHz | ±20ppm | 18pF |
| ABM3-30.000MHZ-B2-T | Abracon晶振 | ABM3 | 30 MHz | ±20ppm | 18pF |
| ABM3-48.000MHZ-B2-T | Abracon晶振 | ABM3 | 48 MHz | ±20ppm | 18pF |
| ABM3-8.000MHZ-D2Y-T | Abracon晶振 | ABM3 | 8 MHz | ±20ppm | 18pF |
| ABM3-10.000MHZ-D2Y-T | Abracon晶振 | ABM3 | 10 MHz | ±20ppm | 18pF |
| ABM3-11.0592MHZ-D2Y-T | Abracon晶振 | ABM3 | 11.0592 MHz | ±20ppm | 18pF |
| ABM3-11.2896MHZ-D2Y-T | Abracon晶振 | ABM3 | 11.2896 MHz | ±20ppm | 18pF |
| ABM3-12.000MHZ-D2Y-T | Abracon晶振 | ABM3 | 12 MHz | ±20ppm | 18pF |
| ABM3-14.31818MHZ-D2Y-T | Abracon晶振 | ABM3 | 14.31818 MHz | ±20ppm | 18pF |
